VP SERIES

Model nº	SC-1523 VP HDR	SC-1525 VP HDR	SC-0615 VP	SC-0719 VP	SC-0725 VP	SC-0826 VP	SC-0829 VP	SC-0839 VP
Pixel Pitch (mm)	2.3	2.5	1.5625	1.953	2.5	2.604	2.976	3.906
LED Type	SMD 1515	SMD 1515	SMD 1212	SMD 1515	SMD 2020	SMD 1515	SMD 2121	SMD 2121
LED Encapsulation	Black Pack	Black Pack	Black Pack	Black Pack	Black Pack	Black Pack	Black Pack	Black Pack
Brightness (nits)	1,500	1,500	600	700	750	800	800	800
Pixel Density (dot/m2)	186.624	160.000	409.600	262.144	160.000	147.456	112.896	65.536
Cabinet Size (mm)	500 x 500	500 x 500	500 x 500	500 x 500	500 x 500	500 x 500	500 x 500	500 x 500
Cabinet Resolution	216 x 216	200 x 200	320 x 320	216 x 216	200 x 200	192 x 192	168 x 168	128 x 128
Max Power Consumpution (W/m2)	720	720	600	600	500	500	500	500
Average Power Consumpution (W/m2)	360	360	225	225	200	200	200	200
Cabinet Weight (Kg)	6.5	6.5	6.5	6.5	6.5	6.5	6.5	6.5
Refresh Rates (Hz)	7.680	7.680	7.680	7.680	7.680	7.680	7.680	7.680
Grey Level (bit)	20	20	16	16	16	16	16	16

Model nº	SC-0725	SC-0826	SC-0829
Application	Indoor (IP 30)	Indoor (IP 30)	Indoor (IP 30)
Pixel Pitch (mm)	2,5	2,604	2,976
LED Encapsulation	SMD 2020	SMD 1515	SMD 2121
Brightness (nits)	750	800	800
Pixel Density (dot/m2)	160.000	147.456	112.896
Module Size (mm)	250 x 250	250 x 250	250 x 250
Module Resolution	100 x 100	96 x 96	84 x 84
Cabinet Size W x H x D (mm)	500 x 500 x 40	500 x 500 x 40	500 x 500 x 40
Cabinet Resolution	200 x 200	192 x 192	168 x 168
Max Power Consumpution (W/m2)	500	500	500
Average Power Consumpution (W/m2)	200	200	200
Cabinet Weight (kg)	4,8	4,8	4,8
Refresh Rates (Hz)	3.840	3.840	3.840
Grey Level	16 Bit	16 Bit	16 Bit
LED Control System	Novastar	Novastar	Novastar

Model nº	XP-8066	XP-8053
Pixel Pitch (mm)	6,60	5,33
Pixel Density (dots/m2)	22.500	35.156
LED Encapsulation	SMD 2727	SMD 2727
Module Size (mm)	320 x 320	320 x 320
Module Resolution	48 x 48	60 x 60
Cabinet Size	960 x 960 x 10 mm	960 x 960 x 10 mm
Cabinet Resolution	144 x 144	180 x 180
Weigth per Cabinet	24.5 kg	24.5 kg
Brightness (cd/m2)	≥ 6.000 (8.000-10.000)	≥ 5.500 (8.000-10.000)
Max Power Consumpution (W/m2)	450	500
Average Power Consumpution (W/m2)	150	175
Energy Saving Design	150	Model
Degree of Protection	2.8 V & 3.8 V Low Voltage Design	2.8 V & 3.8 V Low Voltage Design
Service	Front IP 67 / Rear IP 65	Front IP 67 / Rear IP 65
Power Supply	AC 120/240 V (50 Hz optional)	AC 120/240 V (50 Hz optional)
Refresh Rate (Hz)	≥ 1.920 Hz (3.840 Hz Optional)	≥ 1.920 Hz (3.840 Hz Optional)

Model nº	V3	V5	V10
Pixel Pitch	3.91 - 7.82	5.21 - 10.4	10.4 - 10.4
Max. Brightness Calibrated	5,500 nits	5,500 nits	5,500 nits
Painel Dimension	1000 x 1000 x 82mm
Painel Resolution (H x V)	256 x 128	192 x 96	96 x 96
Weight	17kg / m2
Power Consumption Max/Average	700W / 210W
Transparency	50%	60%	60%
Serviceability	Front
Curving (Concave & Convex)	Concave 10°~Convex 10°
Max. Hanging (panels)	25
Max. Stacking (panels)	50
LED Configuration	SMD 1921	SMD 1921	SMD 2727
Viewing Angle Horizontal	160°
Viewing Angle Vertical	140°
Refresh Rate	3840Hz
Gray Scale	16bit
Frame Material	Aluminium alloy
Operational Temp/Humitidy	~20°~45°C, 10~90% RH
Storage Temp/Humidity	~40°~60°C, 10~90% RH
IP Rating (Front/Rear)	Outdoor
Certifications	ETL, EMC, RoHS

Model nº	F60093	F6012	F60156	F60125	F60156	F65187	F6525
Pixel Configuration	COB	COB	COB	SMD	SMD	SMD	SMD
Pixel Pitch (mm)	0.9375	1.25	1.5625	1.25	1.5625	1.875	2.5
Brightness (nits)	600	600	600	600	600	650	650
Pixel Density (dot/m2)	1.137.778	640.000	409.600	640.000	409.600	284.444	160.000
Module Size (mm)	150x168	150x168	150x168	300x168	300x168	300x168	300x168
Module Resolution	160x180	120x135	96x108	240x135	192x108	160x90	120x68
Cabinet Size (mm)	600x377	600x377	600x377	600x377	600 x 377	600x377	600x377
Cabinet Resolution	640x360	480x270	384x216	480x270	384 x 216	320x180	240x136
Contrast Ratio	30000:1	30000:1	30000:1	50.000:1	50000:1	50000:1	50000:1
Max Power Consumpution (W/m2)	500	500	500	500	500	500	500
Average Power Consumpution (W/m2)	167	167	167	167	167	167	167
Cabinet Weight (kg)	5	5	5	5	5	5	5
Refresh Rates (Hz)	3840	3840	3840	3840	3840	3840	3840
Grey Level (bit)	18	18	18	18	18	18	18

Model nº	W65125	W60153	W58186	W582	W5525	W55307	W60307
Application	Indoor	Indoor	Indoor	Indoor	Indoor	Indoor	Indoor
Pixel Pitch (mm)	1.25	1.538	1.86	2	2.5	3.076	3.076
LED Encapsulation
Pixel Density (dot/m2)	640,000	422,754	289,050	250,000	160,000	105,688	62,500
Module Size (mm)	320x160	320x160	320x160	320x160	320x160	320x160	320x160
Module Resolution	256x128	208x104	172x86	160x80	128x64	104x52	80x40
Cabinet Size (mm)
Max Power Consumpution (W/m2)	650	600	580	580	550	550	600
Average Power Consumpution (W/m2)	220	200	195	195	185	185	200
Display Brightness (nits)	600	600	600	700	750	750	750
Cabinet Weight	21Kg/m2	21Kg/m2	21Kg/m2	21Kg/m2	21Kg/m2	21Kg/m2	21Kg/m2
Refresh Rates (Hz)(bit)	3840	3840	3840	3840	3840	3840	3840
LED Control System
Signal Source	DVI/HDMI/DP	DVI/HDMI/DP	DVI/HDMI/DP	DVI/HDMI/DP	DVI/HDMI/DP	DVI/HDMI/DP	DVI/HDMI/DP
Power Supply	200W	200W	200W	200W	200W	200W	200W
Input Voltage	50/60Hz	50/60Hz	50/60Hz	50/60Hz	50/60Hz	50/60Hz	50/60Hz
Cabinet Materials	Aluminum	Aluminum	Aluminum	Aluminum	Aluminum	Aluminum	Aluminum
Installation	Wall Mounting
